LiF optical windows (custom order)

Material: LiF optical VUV grade
monocrystalline
Working wavelength: 532 nm
Type: circular wedge window
Orientation: 100
Diameter: 2 mm (+0.0/-0.2 mm)
Thickness: 5 mm (+/-0.25 mm)
Finish: 2 sides polished 40/20 scr/dig
Flatness: 5 fringes per inch at 532 nm
Wedge angle on one side 3 deg
(+/- 0.5 deg)
Chamfers: technological for protection from
edge cracks
Coating: none
Part number: LiF_WW_D2_5 certificate of conformity




Material: LiF optical VUV grade
monocrystalline
Working wavelength: 532 nm
Type: circular wedge window
Orientation: 100
Diameter: 2 mm (+0.0/-0.2 mm)
Thickness: 5 mm (+/-0.25 mm)
Finish: 1 sides polished 40/20 scr/dig
(Wedged side)
1 side fine-ground to 320-400 mesh
with 40/20 scr/dig (flat side)
Flatness: 5 fringes per inch at 532 nm
Wedge angle on one side 3 deg
(+/- 0.5 deg)
Chamfers: technological for protection from
edge cracks
Coating: none
Part number: LiF_WWPG_D2_5 - certificate of conformity




Visit our online store or contact us for a custom quote for LiF optics



Online store:

Lithium Fluoride - LiF



 Model   Product Name+   Buy Now
 W-LF-15-5   LiF window ø 15 mm x 5 mm, VUV grade  Buy Now
 W-LF-8.7-3   LiF window ø  8.7 mm x 3 mm  Buy Now
 W-LF-10-3   LiF window ø 10 mm x 3 mm  Buy Now
 W-LF-10-3.5   LiF window ø 10 mm x 3.5 mm  Buy Now
 W-LF-16.4-4   LiF window ø 16.4 mm x 4 mm  Buy Now
 W-LF-16.4-6   LiF window ø 16.4 mm x 6 mm  Buy Now
 W-LF-25.4-3   LiF window ø 25.4 mm x 3 mm  Buy Now
